P3  P3PT1650L

Plug In Transformer

The P3PT1650L is a plug in transformer with LED and fuse protection.

Features

• Single mode protection - hot to neutral
• Secondary termination - 2 #6 – 32 screw terminals.
• LED indicator supervises power
• Primary termination - two (2) male blades.

Specifications

• Primary termination - 120 VAC 60Hz
• Secondary termination: - 17 VAC 50VA (P3PT1650L)
• Clamping voltage - 340V
• Maximum spike current - 4500 AMPS
• Energy dissipation - 60 Joules
• UL listed
• Maximum spike voltage - 6000V
• Clamping response time – 25 nanoseconds
• Dimensions: 2 7/8” (H) x 2 1/4” (W) x 3 7/8” (D).
• Weight: 1.5lbs
