Key Features

• The Only Answer to Modulating on Digital Cable -Guaranteed!
• Eliminates Interference
• No Filters Needed
• Easy Source Switching
• IR Modulation Solution

Technical Specifications

• Forward Gain: CATV in to out 54-1000MHz + 4dB MOD in to out 54-1000MHz -13dB
• Reverse Channel: Out to CATV in 5-42MHz <-7dB
• Isolation: CATV in to TV output 54-1000MHz >50dB (60dB typical)
• MOD in to TV output 54-1000MHz >50dB (60dB typical)
• IR Over Coax: Compatible with Channel Vision IR-4100 and IR-4101 only
• Power Supply: 12VDC, 250mA unregulated
