RTI  RTiPanel

Standard Licence for iPod and iPod Touch devices

RTI Application for your devices

Today’s electronics are converging in new and exciting ways, and the RTiPanel is a perfect example of that. Fully customizable using RTI’s Integration Designer®programming software, the RTiPanel offers the same intuitive control experience RTIremote controls offer, running on the Apple iPad®, iPod Touch®, iPhone® andAndroid™ devices (smart phones and tablets).. Providing secure local or remote access to an RTI XP series control processor from any Internet connection, theRTiPanel allows for LAN control via Wi-Fi and WAN control off site. Users can view and adjust thermostats, monitor security systems and turn off lights, in addition to controlling their A/V electronics, from the office, on vacation, or anywhere in between.

Description

Fully customizable using RTI’s Integration Designer® programming software, theRTiPanel offers the same intuitive control experience RTI remote controls offer, running on an Apple or Android smart phone or tablet device. Providing secure local or remote access to an RTI XP series control processor from any Internet connection, the RTiPanel allows for LAN control via Wi-Fi and WAN control off site. Users can view and adjust thermostats, monitor security systems and turn off lights, in addition to controlling their A/V electronics, from the office, on vacation, or virtually anywhere in between.

* Integration Designer is only available to authorized RTI dealers.

Key Features

• Control and receive feedback from audio, video, lighting, security, climate, and more!
• RTiPanel app available through Apple App Store®, Google Play® and theAmazon App Store®
• Fully integrate Apple iPad®, iPhone®, iPod Touch® and Android™ devices into new or existing RTI control systems utilizing an XP series control processor.
• Completely customizable graphical interface.
• Programmed using same Integration Designer software that is used for allRTI products.
• Supports creation of both portrait and landscape views with minimal extra programming required.
• RTiPanel supports full two-way feedback, including cover art, graphics, text, dynamic scrolling lists, and more!
• Supports local connection via WiFi®, and off-site access via WiFi® or cellular data (if available), with automatic switching.
• Highly optimized for fast connection times.
• Control system programming stored on Apple/Android devices and updates automatically when changes are made.

System Requirements

General

• RTI XP series control processor.
• The device running the RTiPanel App and the XP series control processor must be connected to the Ethernet network.
• Remote access requires a connection to the Internet and either a static IP address from the ISP (Internet Service Provider), or a dynamic DNS account implemented.

Apple iOS Devices

• RTiPanel App compatible with Apple iPad, iPod touch and iPhone.
• Apple devices require iOS 3.2 or higher (* Subject to change without notice.)

Android Devices

• RTiPanel App compatible with Android smart phone and tablet devices.
• Android devices with touchscreen displays larger than 5.5” will require a tablet license.
• Android devices require 2.1 or higher (*Subject to change without notice.)

*Features and system requirements subject to change without notice.

Android is a trademark of Google Inc.

Apple iPad, iPhone, iPod Touch and Apple App Store are registered trademarks of Apple Inc.

RTiPanel App Licensing and Installation info

RTIPanel Installation Notes - PLEASE READ:

• XP control processors will need the latest firmware loaded on them.
• XP-8 control processors may require the installation of an SD flash memory card. (See the RTiPanel installation guide below for more information.)
• RTiPanel licenses are registered to a specific XP processor MAC address. Once registered, licenses are not transferable to another XP processor. No refunds, exchanges or license transfers to another XP processor are allowed. Therefore, verify the MAC address is correct before registering the license.
• If multiple XP processors and RTiPanel Apps will be used in the sameIntegration Designer system file, all of the RTiPanel licenses must be registered to the same XP processor (the gateway processor).

MODELS SUPPORTED

Verify you have the correct model of RTiPanel device in your system file. (For iOS devices, the model number is listed on the back, near the Apple logo. You may need to do a search on the internet to find which generation you have.

Use the following devices in Integration Designer:

• iPad 1, 2, Mini - Use device RTiPanel (iPad) 768x1024
• iPad New/Retina Display (3, 4) - Use device RTiPanel (new Ipad) 1536x2048
• iPhone (original) / iPod Touch (first generation) - Not supported as these devices cannot run iOS 4.0.
• iPhone 3G / iPhone 3GS / iPod Touch (second and third generation) - Use device RTiPanel (iPhone) (320x480)
• iPhone 4 / iPhone 4S / iPod Touch (fourth generation) - Use device RTiPanel(iPhone 4) 640x960
• iPhone 5 / iPod Touch (fifth generation) - Use RTiPanel (iPhone 4) for now. A future update will utilize the full screen height.
• Android Devices: The RTiPanel (Android) is resizable based on the specs of the Android device being used. See the guide below for instructions.

RTiPanel Licensing

How licensing works:

A separate RTiPanel license will need to be purchased for each Apple or Android device in an Integration Designer system file. This is a two-step process, that involves purchasing a license code and redeeming this license code, which will generate the file that will be used to enable the RTiPanel App in the Integration Designer system file.

The actual RTiPanel App is available for download for free from:

• Apple devices: Apple App Store
• Android devices: GooglePlay or Amazon Marketplace

IMPORTANT - PLEASE READ:

• RTiPanel licenses are registered to a specific XP processor MAC address. Once registered, licenses are not transferable to another XP processor. No refunds, exchanges or license transfers to another XP processor are allowed. Therefore, double check the MAC address you are registering the license to, as this cannot be changed.
• Use of the RTiPanel from a remote location requires Internet access for the XP series processor using a dynamic DNS service or a static IP address supplied by the Internet Service Provider (ISP) that is being used at the location.

Step 1) Purchase an RTiPanel License Code

Choose which license you wish to purchase and click the corresponding link below to add an RTiPanel license to your shopping cart. Once your purchase is completed, you will receive an email with your license code.  (ex. 12345678-1234-1234-1234-123456789012)

 Apple iOS Devices

• iPad License - Single Device: This license will allow one Apple iPad, iPhone or iPod Touch to connect to a single XP control processor.
• iPad License - Five Devices: This license will allow up to five Apple iPad, iPhone or iPod Touch devices to connect to a single XP control processor.
• iPhone License - Single Device: This license will allow one Apple iPhone or iPod Touch to connect to a single XP control processor.

Android Devices

• Android Tablet: This license is required for Android devices with displays 5.5 inches and larger.
• Android Phone: This license is required for Android smart phones (displays smaller than 5.5 inches).

Step 2) Generate RTiPanel License File

Once you have received your RTiPanel License code, you must click the Generate License link below to redeem the license code and generate a license file. (Ex. ipad_xx_xx_xx_xx_xx_xx.rtilicense).

To complete this step, you will need the MAC address of the XP processor that thisRTiPanel license will be registered to. The .rtilicense file that is generated is added to your Integration Designer system file under the System Properties.

* To find the MAC address of your XP processor: Go to the Communications>Send to Device menu in your Integration Designer file.
