VTC-IRV30/2810
Vitek
VTC-IRV30/2810
Vitek VTC-IRV30/2810 - 550TVL IR Bullet 2.8-10mm Weather resistant 12/24V. U/M: each
Arizona: Out of Stock
Vegas: Out of Stock
Out of Stock




VTC-IRV30/2810
VTC-IRV30/2810
Day/Night Infrared 550 TV Line Bullet Camera w/100' Range

  • 1/3" Sony Super HAD II CCD w/550TV Lines Resolution
  • 30 Infrared LEDs enable Viewing in Total Darkness up to 100 Feet
  • True ICR Day/Night Function
  • 2.8-10mm Varifocal Auto Iris Lens Included
  • IP66 Rated Weather Resistant Housing with Cable Feed-Thru
  • 24VAC (455mA / 10.92VA) & 12VDC (400mA / 4.8W)
The VTC-IRV30/2810 is a Weather Resistant, self enclosed bullet style IR camera with a 2.8-10mm adjustable focal length auto iris lens. This attractive, compact and economical camera features a Sony Super HAD CCD with 550 TV Lines of Horizontal resolution, 30 Infrared LEDs with range beyond 100’, feed-through wiring, Dual Voltage 12VDC/24VAC operation, and included sunshield.
VTC-IRV30/2810 Specifications:
Image Device 1/3” Sony SuperHAD II Color CCD
Effective Pixels 768 x 494 (NTSC) / 752 x 582 (PAL)
Resolution 550TVL (Day) / 600TVL (Night)
Minimum illumination 0.05Lux / F1.2 (0 Lux with IR LEDs ON)
Infrared LEDs 30 840nm IR LEDs
IR Distance Over 100 Feet
Day/Night Auto
S/N Ratio More than 50dB with AGC off at 50IRE
Electronic Iris 1/60 to 1/100,000 sec.
Built-in Lens 2.8-10.0mm DC A/I / F1.2
Light Compensation Built-in BLC
Iris Mode AES (Auto Electronic Shutter)
Gain Control Auto
White Balance 3,000°K – 8,000°K Automatic tracking
Video Output 1.0Vp-p composite, 75 Ohms
TV System 2:1 Interlace
Scan Frequency 59.94Hz(V), 15.734Khz(V)
Synchronization Internal/Line Lock (Default: Internal)
Water Resistance IP66
Construction Aluminum Housing
Power Source 12VDC/24VAC (Dual Voltage)
Power Consumption 24VAC (455mA / 10.92VA) & 12VDC (400mA / 4.8W)
Operating Conditions 14 – 122 degrees F (-10°C - +50°C /, 85% RH Max
Length Ceiling Mounted: 7.25" (184mm) / Wall Mounted: 8.9" (226mm)
