| Video Input |
8 Channels |
| Video Compression |
H.264 Codec |
| IPS (Display / Recording) |
240 / 240 |
| Operating System |
Linux |
| Operation Mode |
Pentaplex |
| Video Output |
HDMI - 1 1080P (1920 x 1080) |
| BNC Output |
Monitor: 1 Composite (BNC) / Spot: 4 Composite (BNC) |
| Spit-Screen |
Live: 1,4,6,8,9, SEQ / Playback: 1, 4, 9 |
| Audio In/Out |
4 Line In (RCA) / 1 Line Out (RCA), CODEC : G.711 (64Kbps) |
| Storage |
Up to 4 Internal HDD (SATA) + Internal DVD-RW |
| Archive |
CD/DVD-RW / USB Device / Network |
| USB Port |
2 Front + 1 Rear |
| System Control |
Front Panel, USB Mouse, Included IR Remote Control |
| Network |
TCP/IP, HTTP, DHCP (DDNS) |
| RJ-45 Ethernet Port |
10M/100M/1Gbps |
| Search |
Calendar, Event |
| Playback Rate |
240 fps @ 704x480 |
| PTZ |
2 - RS-485 - Supports most of PTZ protocols with up to 255 Presets |
| Point of Sale (POS) |
YES |
| Motion Area Setting |
Adjustable Grid (16 x 12) |
| Recording Resolution Setting |
By each camera for different resoultion setting(CIF/2CIF/D1) |
| Recording Quality Control |
4 Levels (Low/Standard/High/Highest) |
| Recording Schedule |
By hour, by day, by recording mode, By alarm, By Ch |
| Panic Record |
Overrides all other recording settings to provide the best quality recording |
| Pre-recording |
Max. 5 seconds |
| Post-recording |
Max. 180 seconds |
| Player |
Backup player, Window Media Player and HDD PC Viewer |
| E-mail notification |
E-mails to specific users to notify events |
| System Configuration |
Full setup configuration over network |
| Bandwidth limit |
YES: Adjustable by User |
| Two-Way Audio |
YES |
| Power |
12V Adaptor, 3.3A, 100~220VAC, 50~60Hz |
| Operating Temperature |
32° ~ 104°F (0° ~ 40°C) |
| Humidity |
10 ~ 90% NC |
| Case Form Factor |
2U |
| Dimensions |
17” x 4” x 18” |
