Sanus XF228
Full-Motion Wall Mount
Dual extension arms for 42" – 84" flat-panel TVs — extends 28" / 71.12 cm
The SANUS HDpro™ Series XF228 features a pre-assembled interface and strong, ultra-light extruded aluminum wall plate for the quickest, easiest installation possible. The QuickConnect™ system allows the mounting head to snap onto the arm assembly with one easy movement and unlock with the push of a tab. ProSet™ post-installation height and leveling adjustments ensure the TV is always perfectly positioned after mounting. The XF228 arm assembly shifts left and right on the wall plate for easy TV centering, even with off-center wall studs. And the amazing FollowThru™ in-arm cable channel protects and completely conceals all cables without inhibiting movement, even through the elbow. Strong dual arms allow even the largest TVs to extend, retract, tilt and swivel up to 28" / 71.12 cm from the wall with ease. Virtual Axis™ tilting technology allows effortless viewing angle adjustment with the push of a finger. Universal mounting brackets. Mount now fits TVs 42” – 84” weighing up to 175 lbs, and all current XF228 models have been tested for compatibility with the updated size range.
Features
- FollowThru™ in-arm channel completely conceals all cables without inhibiting movement, even through the elbow
- Virtual Axis™ provides smooth tilt motion with the touch of a fingertip
- Open wall plate design provides generous space for cable management
- ProSet™ height and leveling adjustments allow TV to be perfectly positioned after hanging
- Full-motion mount extends, pans, tilts and swivels for easy viewing anywhere in a room
- Finalist of the CE Pro Best Award 2009
- HDpro™ products made with the custom installer in mind
Check out the features video on this mount
Specifications
- Model Code: XF228
- Price: $649.99
- UPC Code: XF228-B1-793795363787-Black
- Product Width: 34.00" / 86.36 cm
- Product Height: 23.00" / 58.42 cm
- Product Depth Max: 28.00" / 71.12 cm
- Product Depth Min: 3.25" / 8.26 cm
- Package Width: 37.5" / 95.25 cm
- Package Height: 5.80" / 14.73 cm
- Package Depth: 25.50" / 64.77 cm
- TV Size Range: 42.00" - 84.00" / 106.68cm - 213.36cm
- Maximum TV Weight: 175.00 lb / 79.55 kg
- Mounting Pattern: Universal
- Tilt: 5.00° / - 15.00°
- Swivel: 75.00° / - 75.00°
- Roll: 5.00° / - 5.00°
QuickConnect™
The QuickConnect™ system makes it easy to attach your TV to the mount's arm assembly and lock it in place in one easy movement.
- Simply insert the locking tab on the monitor plate into the opening on the arm assembly and let it slide downward into place
- An audible click will let you know the parts are correctly assembled
- To remove your TV, just push in on the locking tab to disengage it from the arm assembly
ProSet™
Once installed, your TV or wall-mounted furniture may not appear completely level with its surroundings. ProSet™ technology lets you make micro-adjustments to height and level after mounting to ensure perfect positioning.
- Simply tighten or loosen the ProSet™ adjustment feature for a flawless appearance
FollowThru™
This innovative in-arm cable channel protects and conceals cables the entire length of the extension arm without inhibiting movement, even through the elbow.
- Exclusive design allows mount to extend, retract and pan with the easiest, most fluid motion possible
- An adjustable tension ring lets you find and keep the perfect position for your TV
- Decorative covers conceal cables inside the arm after they're installed for a seamless appearance
Virtual Axis™
This exclusive patented technology allows smooth, easy tilting motion by balancing the weight of the TV on itself.
- Tilt your TV up or down with just the touch of a finger — no tools are required to adjust the viewing angle
- Easily reduce glare and reflections caused by lights or windows
